Learning Basic Features
Group
Code
Name
LCD Display
Parameter
Setting
Setting
Range
Unit
voltage
46
Invert V2 rotational
direction
V2 Inverting
0
No
0–1
-
47
V2 quantizing level
V2 Quantizing
0.04
0.00*, 0.04–
10.00
%
* Quantizing is disabled if ‘0’ is selected.
Setting a Frequency with TI Pulse Input
Set a frequency reference by setting the Frq (Frequency reference source) code in
Operation group to 12 (Pulse). In case of Standard I/O (excluding 30-75kW models), set the
In.69 P5 Define to 54(TI) and providing 0–32.00kHz pulse frequency to P5.
Group
Code
Name
LCD Display
Parameter
Setting
Setting
Range
Unit
Operation
Frq
Frequency
reference source
Freq Ref Src
12
Pulse
0–12
-
In
69
P5 terminal
function setting
P5 Define
54
TI
0-54
-
01
Frequency at
maximum analog
input
Freq at 100%
60.00
0.00–
Maximum
frequency
Hz
91
Pulse input
display
Pulse Monitor
0.00
0.00–50.00
kHz
92
TI input filter time
constant
TI Filter
10
0–9999
ms
93
TI input minimum
pulse
TI Pls x1
0.00
0.00–32.00
kHz
94
Output% at TI
minimum pulse
TI Perc y1
0.00
0.00–100.00
%
95
TI Input maximum
pulse
TI Pls x2
32.00
0.00–32.00
kHz
96
Output% at TI
maximum pulse
TI Perc y2
100.00
0.00–100.00
%
97
Invert TI direction
of rotation
TI Inverting
0
No
0–1
-
98
TI quantizing level
TI Quantizing
0.04
0.00*, 0.04–
10.00
%
* Data shaded in grey is applied only for Standard I/O (excluding 30-75kW models).
*Quantizing is disabled if ‘0’ is selected.
