LSIS LSLV-S100 User Manual

402
Technical Specification
Note
Precautions for 1–phase input to 3-phase drive
• Please connect single-phase input to R(L1) and T(L3).
• AC or DC reactor is necessary to reduce DC ripple. Please select built-in reactor type
for 30-75kW. For 0.4-22kW, external AC or DC reactor should be installed.
• Same peripheral devices (including a fuse and reactor) as 3-phase can be used for 1-
phase as well.
• If phase open trip occurs, please turn off the input phase open protection(PR-05).
• Protection for output current like OCT or IOLT is based on 3-phase input ratings which
is larger than single-phase input. User should set the parameters that are relative to
motor information(bA-11~16), overload trip(Pr-17~22) and E-thermal functions(Pr-
40~43)
• Performance of sensorless control could be unstable depending on DC ripple.
• The minimum input voltage must be larger than 228Vac for 240Vac supply and 456Vac for
480Vac supply to ensure motor voltage production of 207Vac and 415Vac, respectively.
• To minimize the effect of voltage deprivation, please choose 208Vac motor for 240Vac
supply and 400Vac motor for 480Vac supply.
30-75kW Models
3-Phase 400 V (30–75 kW)
Model □□□□ S100–4 □□□
0300
0370
0450
0550
0750
Applied
motor
HP
40
50
60
75
100
kW
30
37
45
55
75
Rated
output
Rated
capacity
[440Vac
input] (kVA)
Heavy load
46
57
69
84
116
Normal load
55
67
78
106
126
Rated current
[3-Phase
input] (A)
Heavy load
61
75
91
110
152
Normal load
75
91
107
142
169
Rated current
[Single-
Phase input]
(A)
Heavy load
32
39
47
57
78
Normal load
39
47
55
73
87
Output frequency
0-400 Hz (IM Sensorless: 0-120 Hz)
Output voltage (V)
3-phase 380-480 V
Rated
input
Working voltage (V)
3-phase 380-480 VAC (-15% to +10%)
Single phase 480VAC(-5% to +10%)
