LSIS LSLV-S100 User Manual

Technical Specification
419
Items
W1
W2
H1
H2
H3
D1
D2
A
Φ
T1
T2
3-
phase
200V
0110S100-2
260
(10.24)
229
(9.02)
399.6
(15.73)
377
(14.84)
14.6
(0.57)
245.4
(9.66)
259.6
(10.22)
6
(0.24)
-
22.3
(0.88)
34.9
(1.37)
0150S100-2
300
(11.81)
270.8
(10.66)
460
(18.11)
436.5
(17.19)
15.5
(0.61)
250
(9.84)
264
(10.39)
6
(0.24)
-
22.3
(0.88)
44.5
(1.75)
3-
phase
400V
0110S100-4
260
(10.24)
229
(9.02)
399.6
(15.73)
377
(14.84)
14.6
(0.57)
245.4
(9.66)
259.6
(10.22)
6
(0.24)
-
22.3
(0.88)
34.9
(1.37)
0150S100-4
0185S100-4
300
(11.81)
270.8
(10.66)
460
(18.11)
436.5
(17.19)
15.5
(0.61)
250
(9.84)
264
(10.39)
6
(0.24)
-
22.3
(0.88)
44.5
(1.75)
0220S100-4
Units: mm (inches)
11.4 Peripheral Devices
0.4-22kW Models
Compatible Circuit Breaker, Leakage Breaker and Magnetic Contactor Models
(manufactured by LSIS)
Product
(kW)
Circuit Breaker
Leakage Breaker
Magnetic Contactor
Model
Current
(A)
Model
Current
(A)
Model
Current
(A)
Model
Current
(A)
Single
phase
200V
0.4
ABS33c
5
UTE100
15
EBS33c
5
MC-6a
9
0.75
10
10
MC-9a,
MC-9B
11
1.5
15
15
MC-18a,
MC-18B
18
2.2
20
20
20
MC-22b
22
3-
phase
200V
0.4
ABS33c
5
UTE100
15
EBS33c
5
MC-6a
9
0.75
10
10
MC-9a,
MC-9b
11
1.5
15
15
MC-18a,
MC-18b
18
2.2
20
20
20
MC-22b
22
3.7
30
30
30
MC-32a
32
4
5.5
ABS53c
50
50
EBS53c
50
MC-50a
55
7.5
ABS63c
60
60
EBS63c
60
MC-65a
65
