Learning Protection Features
269
Inverter Diagnosis State
Check the diagnosis of components or devices for inverter to check if they need to be
replaced.
Group
Code
Name
LCD Display
Parameter
Setting
Setting Range
Unit
Pr
89
CAP, FAN
replacement
warning
Inverter State
00
Bit
00-10
Bit
00
-
01
CAP Warning
10
FAN Warning
Operation Mode on Option Card Trip
Option card trips may occur when an option card is used with the inverter. Set the operation
mode for the inverter when a communication error occurs between the option card and the
inverter body, or when the option card is detached during operation.
Group
Code
Name
LCD Display
Parameter
Setting
Setting range
Unit
Pr
80
Operation mode on
option card trip
Opt Trip Mode
0
None
0-3
-
1
Free-Run
2
Dec
Operation Mode on Option Trip Setting Details
Code
Description
Pr.80 Opt Trip
Mode
Setting
Function
0
None
No operation
1
Free-Run
The inverter output is blocked and fault trip
information is shown on the keypad.
2
Dec
The motor decelerates to the value set at Pr.07
(Trip Dec Time).
