5.10 Sensorless Vector Control for Induction Motors
Sensorless vector control is an operation to carry out vector control without the rotation
speed feedback from the motor but with an estimation of the motor rotation speed
calculated by the inverter. Compared to V/F control, sensorless vector control can generate
greater torque at a lower level of current.
Group
Code
Name
LCD Display
Parameter Setting
Setting
Range
Unit
dr
09
Control mode
Control Mode
4
IM Sensorless
-
-
14
Motor capacity
Motor
Capacity
Depends on the
motor capacity
0-15
-
18
Base frequency
Base Freq
60
30-400
Hz
bA
11
Motor pole number
Pole Number
4
2-48
-
12
Rated slip speed
Rated Slip
Depends on the
motor capacity
0-3000
Hz
13
Rated motor current
Rated Curr
Depends on the
motor capacity
1-1000
A
14
Motor no-load current
Noload curr
Depends on the
motor capacity
0.5-1000
A
15
Rated motor voltage
Rated Volt
220/380/440/480
170-480
V
16
Motor efficiency
Efficiency
Depends on the
motor capacity
64-100
%
20
Auto tuning
Auto Tuning
1
All
-
-
Cn
09
Pre-Excite time
PreExTime
1.0
0.0-60.0
s
10
Pre-Excite amount
Flux Force
100.0
100.0-300.0
%
20
Sensorless second
gain display setting
SL2 G View
Sel
1
Yes
0-1
-
21
Sensorless speed
controller proportional
gain1
ASR-SL P
Gain1
Depends on the
motor capacity
0-5000
%
22
Sensorless speed
controller integral gain 1
ASR-SL I
Gain1
Depends on the
motor capacity
10-9999
ms
23*
Sensorless speed
controller proportional
gain 2
ASR-SL P
Gain2
Depends on the
motor capacity
1-1000
%
24*
Sensorless speed
controller integral gain 2
ASR-SL I
Gain2
Depends on the
motor capacity
1-1000
%
26*
Flux estimator
proportional gain
Flux P Gain
Depends on the
motor capacity
10-200
%
27*
Flux estimator integral
gain
Flux I Gain
Depends on the
motor capacity
10-200
%
28*
Speed estimator
proportional gain
S-Est P
Gain1
Depends on the
motor capacity
0-32767
-
29*
Speed estimator
integral gain1
S-Est I Gain1
Depends on the
motor capacity
100-1000
-
30*
Speed estimator
S-Est I Gain2
Depends on the
100-10000
-
