LSIS LSLV-S100 User Manual

Technical Specification
397
11 Technical Specification
11.1 Input and Output Specification
0.4-22kW Models
Single Phase 200V (0.4-2.2 kW)
Model □□□□ S100 – 1 □□□□□
0004
0008
0015
0022
Applied
motor
Heavy load
HP
0.5
1.0
2.0
3.0
kW
0.4
0.75
1.5
2.2
Normal load
HP
1.0
2.0
3.0
5.0
kW
0.75
1.5
2.2
3.7
Rated
output
Rated
capacity (kVA)
Heavy
load
1.0
1.9
3.0
4.2
Normal
load
1.2
2.3
3.8
4.6
Rated current
(A)
Heavy
load
2.5
5.0
8.0
11.0
Normal
load
3.1
6.0
9.6
12.0
Output frequency
0-400 Hz (IM Sensorless: 0-120 Hz)
Output voltage (V)
3-phase 200-240 V
Rated input
Working voltage (V)
Single phase 200-240 V AC (-15% to +10%)
Input frequency
50-60 Hz (±5%)
Rated current
(A)
Heavy
load
4.4
9.3
15.6
21.7
Normal
load
5.8
11.7
19.7
24.0
Weight (lb /kg)
(Built-in EMC filter)
2/0.9
(2.5/1.14)
2.86/1.3
(3.9/1.76)
3.3/1.5
(3.9/1.76)
4.4/2.0
(4.9/2.22)
• The standard motor capacity is based on a standard 4-pole motor.
• The standard used for 200 V inverters is based on a 220 V supply voltage, and for
400V inverters is based on a 440 V supply voltage.
• The rated output current is limited based on the carrier frequency set at Cn.04.
• The output voltage becomes 20~40% lower during no-load operations to protect the
inverter from the impact of the motor closing and opening (0.4-4.0kW models only).
• IP66 models do not support normal load operation.
