Technical Specification
425
11.7 Dynamic Braking Unit(DBU) and Resistors
Braking Resistor Specification (0.4-22kW)
Product (kW)
Resistance ( Ω )
Rated Capacity (W)
Single phase
200V
0.4
300
100
0.75
150
150
1.5
60
300
2.2
50
400
3-phase
200V
0.4
300
100
0.75
150
150
1.5
60
300
2.2
50
400
3.7
33
600
4
33
600
5.5
20
800
7.5
15
1,200
11
10
2,400
15
8
2,400
3-phase
400V
0.4
1,200
100
0.75
600
150
1.5
300
300
2.2
200
400
3.7
130
600
4
130
600
5.5
85
1,000
7.5
60
1,200
11
40
2,000
15
30
2,400
18.5
20
3,600
22
20
3,600
• The standard for braking torque is 150% and the working rate (%ED) is 5%. If the
working rate is 10%, the rated capacity for braking resistance must be calculated at
twice the standard.
