LSIS LSLV-S100 User Manual

148
Learning Basic Features
Slave Parameter
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
CM
95
P2P
Communication
selection
Int 485 Func
2
P2P Slave
0–3
-
96
P2P DO setting
selection
P2P OUT Sel
0
No
0–2
bit
P2P Setting Details
Code
Description
CM.95 Int 485 Func
Set master inverter to 1(P2P Master), slave inverter to 2(P2P
Slave).
US.80–82 P2P Input Data
Input data sent from the slave inverter.
US.85, 88 P2P Output Data
Output data transmitted to the slave inverter.
• P2P features work only with code version 1.00, IO S/W version 0.11, and keypad S/W
version 1.07 or higher versions.
• Set the user sequence functions to use P2P features..
4.22 Multi-keypad Setting
Use multi-keypad settings to control more than one inverter with one LCD keypad. To use
this function, first configure RS-485 communication.
The group of inverters to be controlled by the keypad will include a master inverter. The
master inverter monitors the other inverters, and slave inverter responds to the master
inverter’s input. When using multi-function output, a slave inverter can select to use either
the master inverter’s output or its own output. When using the multi keypad, first designate
the slave inverter and then the master inverter. If the master inverter is designated first,
connected inverters may interpret the condition as a loss of communication.
Master Parameter
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
CM
95
P2P
Communication
selection
Int 485 Func
3
KPD-Ready
0–3
-
CNF
03
Multi-keypad ID
Multi KPD ID
3
3–99
-
42
Multi-function key
selection
Multi Key Sel
4
Multi KPD
0–4
-
