11.8 Continuous Rated Current Derating
Carrier Frequency Setting Range and Default Values (by product capacity)
Refer to the following graphs for carrier frequency ranges and default values by product
capacity.
Capacity
Heavy Duty
Normal Duty
Setting Range
Default
Values
Setting Range
Default
Values
V/F
S/L
V/F
S/L
Min.
Max.
Min.
Max.
Min.
Max.
Min.
Max.
0.4-4.0kW
2
15
2
15
3
2
5
2
5
2
5.5-22kW
1
15
2
15
1
5
2
5
30-45kW
1
10
2
10
1
5
2
5
55/75kW
1
7
2
7
1
3
2
3
Continuous Rated Current Derating by Carrier Frequency
The continuous rated current of the inverter is limited based on the carrier frequency. Refer
to the following graph.
Continuous Rated Current Graph (0.4-22kW Heavy Duty)
Carrier frequency
(kHz)
Continuous rated current
