LSIS LSLV-S100 User Manual

RS-485 Communication Features
277
Group
Code
Name
LCD Display
Parameter
Setting
Setting range
Unit
33
Multi-function output 1
Q1 Define
Command
Group
Code
Name
LCD Display
Parameter
Setting
Setting range
Unit
Operation
DRV
Command
source
Cmd Source*
3
Int 485
0-5
-
Frq
Frequency
setting method
Freq Ref Src
6
Int 485
0-12
-
* Displayed in DRV-06 on an LCD keypad.
Command Loss Protective Operation
Configure the command loss decision standards and protective operations run when a
communication problem lasts for a specified period of time.
Command Loss Protective Operation Setting Details
Code
Description
Pr.12 Lost Cmd
Mode,
Pr.13 Lost Cmd
Time
Select the operation to run when a communication error has occurred and
lasted exceeding the time set at Pr. 13.
Setting
Function
0
None
The speed command immediately becomes the
operation frequency without any protection
function.
1
Free-Run
The inverter blocks output. The motor performs
in free-run condition.
2
Dec
The motor decelerates and then stops at the
time set at Pr.07 (Trip Dec Time).
3
Hold Input
The inverter calculates the average input value
for 10 seconds before the loss of the speed
command and uses it as the speed reference.
4
Hold Output
The inverter calculates the average output value
for 10 seconds before the loss of the speed
command and uses it as the speed reference.
5
Lost Preset
The inverter operates at the frequency set at Pr.
14 (Lost Preset F).
