Learning to Perform Basic Operations
64
Control Menu
0.4-22kW Control Menu
The following table lists the functions groups under Parameter mode.
Function Group
Name
Keypad
Display
LCD
Display
Description
Operation
0.00
DRV-01
Configures reference frequencies.
ACC
DRV-03
Configures acceleration times.
DEC
DRV-04
Configures deceleration times.
DRV
DRV-06
Used to select operation command.
FRQ
DRV-07
Configures operation frequencies.
ST1
BAS-50
Configures the Step Freq. 1 of the multi-step
frequencies.
ST2
BAS-51
Configures Step Freq. 2 of the multi-step
frequencies.
ST3
BAS-52
Configures Step Freq. 2 of the multi-step
frequencies.
CUR
Monitor Line
Display
(CNF-20~23)
Displays current output current.
RPM
Displays current speed of a load (RPM).
DCL
Displays current DC LINK voltage.
VOL
Displays current output voltage.
NON
TRP Last-1
Displays recent trip history.
DRC
-
Used to select motor operation direction.
Drive
dr
DRV
Configures parameters for basic operations.
These include jog operation, motor capacity
evaluation, torque boost, and other keypad
related parameters.
Basic
ba
BAS
Configures basic operation parameters. These
parameters include motor parameters and
multi-step frequency parameters.
Advanced
ad
ADV
Configures acceleration or deceleration
patterns, frequency limits, etc.
Control
cn
CON
Configures sensorless vector-related features.
Input Terminal
in
IN
Configures input terminal–related features,
including digital multi–functional inputs and
analog inputs.
Output Terminal
ou
OUT
Configures output terminal–related features
such as relays and analog outputs.
