LSIS LSLV-S100 User Manual

RS-485 Communication Features
289
7.4 Compatible Common Area Parameter
The following are common area parameters compatible with iS5, iP5A, iV5, and iG5A.
Comm.
Address
Parameter
Scale
Unit
R/W
Assigned Content by Bit
0h0000
Inverter model
-
-
R
6: S100
0h0001
Inverter capacity
-
-
R
0: 0.75 kW, 1: 1.5 kW, 2: 2.2 kW
3: 3.7 kW, 4: 5.5 kW, 5: 7.5 kW
6: 11 kW, 7: 15 kW, 8: 18.5 kW
9: 22 kW, 10: 30 kW, 11: 37 kW
12: 45 kW, 13: 55 kW, 14: 75 kW
256: 0.4 kW, 257: 1.1 kW, 258: 3.0 kW
259: 4.0 kW
0h0002
Inverter input
voltage
-
-
R
0: 220V product
1: 440V product
0h0003
Version
-
-
R
Example 0h0100: Version 1.00
Example 0h0101: Version 1.01
0h0004
Reserved
-
-
R/W
0h0005
Command
frequency
0.01
Hz
R/W
0h0006
Operation
command (option)
-
-
R
B15
Reserved
B14
0: Keypad Freq,
1: Keypad Torq
2-16: Terminal block multi-
step speed
17: Up, 18: Down
19: STEADY
22: V1, 24: V2, 25: I2,
26: Reserved
27: Built-in 485
28: Communication option
30: JOG, 31: PID
B13
B12
B11
B10
B9
B8
0: Keypad
1: Fx/Rx-1
2: Fx/Rx-2
3: Built-in 485
4: Communication option
B7
B6
R/W
B5
Reserved
B4
Emergency stop
B3
W: Trip initialization (01),
R: Trip status
B2
Reverse operation (R)
B1
Forward operation (F)
B0
Stop (S)
0h0007
Acceleration time
0.1
s
R/W
-
0h0008
Deceleration time
0.1
s
R/W
-
