Table of Functions
376
8.14 Groups for LCD Keypad Only
Trip Mode (TRP Last-x)
Code
Name
LCD Display
Setting Range
Initial Value
Ref.
00
Trip type display
Trip Name(x)
-
-
-
01
Frequency reference at
trip
Output Freq
-
-
-
02
Output current at trip
Output Current
-
-
-
03
Acceleration/Deceleration
state at trip
Inverter State
-
-
-
04
DC section state
DCLink Voltage
-
-
-
05
NTC temperature
Temperature
-
-
-
06
Input terminal state
단자대 상태
DI Status
-
0000 0000
-
07
Output terminal state
DO Status
-
000
-
08
Trip time after Power on
Trip On Time
-
0/00/00 00:00
-
09
Trip time after operation
start
Trip Run Time
-
0/00/00 00:00
-
10
Delete trip history
Trip Delete?
0
No
1
Yes
Config Mode (CNF)
Code
Name
LCD Display
Setting Range
Initial Value
Ref.
00
Jump code
Jump Code
1-99
42
p.71
01
Keypad language
selection
Language Sel
0 : English
0 : English
p.246
02
LCD constrast
adjustment
LCD Contrast
-
-
p.229
03
Multi keypad ID
Multi KPD ID
3-99
3
p.148
10
Inverter S/W version
Inv S/W Ver
-
-
p.229
11
LCD keypad S/W
version
Keypad S/W Ver
-
-
p.229
12
LCD keypad title version
KPD Title Ver
-
-
p.229
20
Status window display
item
Anytime Para
0
Frequency
0: Frequency
p.246
