LSIS LSLV-S100 User Manual

RS-485 Communication Features
292
7.5 S100 Expansion Common Area Parameter
Monitoring Area Parameter (Read Only)
Comm.
Address
Parameter
Scale
Unit
Assigned content by bit
0h0300
Inverter model
-
-
S100: 0006h
0h0301
Inverter capacity
-
-
0.4kW : 1900h, 0.75kW: 3200h
1.1kW: 4011h, 1.5kW: 4015h
2.2kW: 4022h, 3.0kW: 4030h
3.7kW: 4037h, 4.0kW: 4040h
5.5kW: 4055h, 7.5kW: 4075h
11kW: 40B0h, 15kW: 40F0h
18.5kW: 4125h, 22kW: 4160h
30kW: 41E0h, 37kW: 4250h
45kW: 42D0h, 55kW: 4370h
75kW: 44B0h
0h0302
Inverter input
voltage/power
(Single phase, 3-
phase)/cooling
method
-
-
100 V single phase self cooling: 0120h,
200 V 3-phase forced cooling: 0231h
100 V single phase forced cooling: 0121h,
400 V single phase self cooling: 0420h
200 V single phase self cooling: 0220h,
400 V 3-phase self cooling: 0430h
200 V 3-phase self cooling: 0230h, 400 V
single phase forced cooling: 0421h
200 V single phase forced cooling: 0221h,
400 V 3-phase forced cooling: 0431h
0h0303
Inverter S/W
version
-
-
(Ex) 0h0100: Version 1.00
0h0101: Version 1.01
0h0304
Reserved
-
-
-
0h0305
Inverter operation
state
-
-
B15
0: Normal state
4: Warning occurred
8: Fault occurred [operates
according to Pr. 30 (Trip Out
Mode) setting.]
B14
B13
B12
B11 -
-
B8
B7
1: Speed searching
2: Accelerating
3: Operating at constant rate
4: Decelerating
B6
B5
