Learning Basic Features
Group
Code
Name
LCD Display
Parameter
Setting
Setting
Range
Unit
AP
02
User sequence
activation
User Seq En
0
0–1
-
US
01
User sequence
operation command
User Seq Con
0
0–2
-
02
User sequence
operation time
User Loop
Time
0
0–5
-
11–
28
Output address link1–18
Link UserOut
1–18
0
0–0xFFFF
-
31–
60
Input value setting1–30
Void Para1–30
0
-9999–9999
-
80
Analog input 1
P2P In V1
(-10–10 V)
0
0–12,000
%
81
Analog input 2
P2P In I2
0
-12,000
%
82
Digital input
P2P In D
0
–12,000
bit
85
Analog output
P2P Out AO1
0
0–0x7F
%
88
Digital output
P2P Out DO
0
0–0x03
bit
UF
01
User function 1
User Func1
0
0–28
-
02
User function input 1-A
User Input 1-A
0
0–0xFFFF
-
03
User function input 1-B
User Input 1-B
0
0–0xFFFF
-
04
User function input 1-C
User Input 1-C
0
0–0xFFFF
-
05
User function output 1
User Output 1
0
-32767–
32767
-
06
User function 2
User Func2
0
0–28
-
07
User function input 2-A
User Input 2-A
0
0–0xFFFF
-
08
User function input 2-B
User Input 2-B
0
0–0xFFFF
-
09
User function input 2-C
User Input 2-C
0
0–0xFFFF
-
10
User function output 2
User Output 2
0
-32767–
32767
-
11
User function 3
User Func3
0
0–28
-
12
User function input 3-A
User Input 3-A
0
0–0xFFFF
-
13
User function input 3-B
User Input 3-B
0
0–0xFFFF
-
14
User function input 3-C
User Input 3-C
0
0–0xFFFF
-
15
User function output 3
User Output 3
0
-32767–
32767
-
16
Uer function 4
User Func4
0
0–28
-
17
User function input 4-A
User Input 4-A
0
0–0xFFFF
-
18
User function input 4-B
User Input 4-B
0
0–0xFFFF
-
19
User function input 4-C
User Input 4-C
0
0–0xFFFF
-
