LSIS LSLV-S100 User Manual

153
Learning Basic Features
Group
Code
Name
LCD Display
Parameter
Setting
Setting
Range
Unit
80
User function output 16
User Output 16
0
-32767–
32767
-
81
User function 17
User Func17
0
0–28
-
82
User function input 17-A
User Input 17-A
0
0–0xFFFF
-
83
User function input 17-B
User Input 17-B
0
0–0xFFFF
-
84
User function input 17-C
User Input 17-C
0
0–0xFFFF
-
85
User function output 17
User Output 17
0
-32767–
32767
-
86
User function 18
User Func18
0
0–28
-
87
User function input 18-A
User Input 18-A
0
0–0xFFFF
-
88
User function input 18-B
User Input 18-B
0
0–0xFFFF
-
89
User function input 18-C
User Input 18-C
0
0–0xFFFF
-
90
User function output 18
User Output 18
0
-32767–
32767
-
User Sequence Setting Details
Code
Description
AP.02 User Seq En
Display the parameter groups related to a user sequence.
US.01 User Seq Con
Set Sequence Run and Sequence Stop with the keypad.
Parameters cannot be adjusted during an operation. To adjust
parameters, the operation must be stopped.
US.02 User Loop Time
Set the user sequence Loop Time.
User sequence loop time can be set to 0.01s/0.02s/
0.05s/0.1s/0.5s/1s.
US.11–28
Link UserOut1–18
Set parameters to connect 18 Function Blocks. If the input value is
0x0000, an output value cannot be used.
To use the output value in step 1 for the frequency reference (Cmd
Frequency), input the communication address(0x1101) of the Cmd
frequency as the Link UserOut1 parameter.
US.31–60 Void
Para1–30
Set 30 void parameters. Use when constant (Const) parameter input
is needed in the user function block.
UF.01–90
Set user defined functions for the 18 function blocks.
If the function block setting is invalid, the output of the User Output@ is
-1. All the outputs from the User Output@ are read only, and can be
used with the user output link@ (Link UserOut@) of the US group.
