LSIS LSLV-S100 User Manual

Learning Advanced Features
195
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
Ld and Lq
Lev
35
Auto tuning
frequency for Ld
and Lq
Ld,Lq Tune
Hz
100.0%
80.0–150.0
%
Cn
12
PM speed
controller P gain 1
ASR P Gain 1
100
0–5000
-
13
PM speed
controller I gain 1
ASR I Gain 1
150
0–5000
-
15
PM speed
controller P gain 2
ASR P Gain 2
100
0–5000
-
16
PM speed
controller I gain 2
ASR I Gain 2
150
0–9999
-
33
PM D-axis back-
EMF estimated
gain (%)
PM EdGain
Perc
100.0
0–300.0
%
34
PM Q-axis back-
EMF estimated
gain (%)
PM EqGain
Perc
100.0
0–300.0
%
35
Initial pole position
estimation retry
PD Repeat
Num
2
0–10
-
36
Initial pole position
estimation interval
Pulse Interval
20
1–100
ms
37
Initial pole position
estimation pulse
current (%)
Pulse Curr %
15
10–100
%
38
Initial pole position
estimation pulse
voltage (%)
Pulse Volt %
500
100–4000
-
39
PM dead-time
range (%)
PMdeadBand
Per
100.0
50.0–200.0
%
40
PM dead-time
voltage (%)
PMdeadVolt
Per
100.0
50.0–200.0
%
41
PM speed
estimator
proportional gain
PM SpdEst
Kp
100
0–32000
-
42
PM speed
estimator integral
gain
PM SpdEst Ki
10
0–32000
-
43
PM speed
estimator
proportional gain 2
PM SpdEst
Kp 2
300
0–32000
-
44
PM speed
estimator integral
gain 2
PM SpdEst Ki
2
30
0–32000
-
45
Speed estimator
feedforward high
speed range (%)
PM Flux FF %
300
0–1000
%
