LSIS LSLV-S100 User Manual

254
Learning Protection Features
Group
Code
Name
LCD Display
Parameter Setting
Setting range
Unit
57
Stall frequency 4
Stall Freq 4
60.00
Stall Freq 3–
Maximum
frequency
Hz
58
Stall level 4
Stall Level 4
180
30-250
%
OU
31
Multi-function relay 1
item
Relay 1
9
Stall
-
-
32**
Multi-function relay 2
item
Relay 2
33
Multi-function output
1 item
Q1 Define
* The value is displayed on the keypad as .
** Available for 30-75kW models only.
Stall Prevention Function and Flux Braking Setting Details
Code
Description
Pr.50 Stall
Prevent
Stall prevention can be configured for acceleration, deceleration, or while
operating a motor at constant speed. When the top LCD segment is on, the
corresponding bit is set. When the bottom LCD segment is on, the
corresponding bit is off.
Item
Bit Status (On)
Bit Status (Off)
Keypad
LCD keypad
Setting
Function
Bit 4
Bit 3
Bit 2
Bit 1

Stall protection during acceleration

Stall protection while operating at a
constant speed

Stall protection during deceleration

Flux braking during deceleration
Setting
Function
0001
Stall
protection
during
acceleration
If inverter output current exceeds the preset stall
level (Pr. 52, 54, 56, 58) during acceleration, the
motor stops accelerating and starts decelerating. If
current level stays above the stall level, the motor
decelerates to the start frequency (dr.19). If the
current level causes deceleration below the preset
level while operating the stall protection function,
the motor resumes acceleration.
