Table of Functions
351
Code
Comm.
Address
Name
LCD Display
Setting Range
Initial
Value
Property
*
V/
F
SL
Ref.
05
0h1C05
Deceleration
time
M2-Dec
Time
0.0-600.0(s)
30.0
O/A
O
I
p.218
06
0h1C06
Motor capacity
M2-
Capacity
0
0.2 kW
-
X/A
O
I
p.218
1
0.4 kW
2
0.75 kW
3
1.1 kW
4
1.5 kW
5
2.2 kW
6
3.0 kW
7
3.7 kW
8
4.0 kW
9
5.5 kW
10
7.5 kW
11
11.0 kW
12
15.0 kW
13
18.5 kW
14
22.0 kW
15
30.0 kW
16
37.0 kW
17
45.0 kW
18
55.0 kW
19
75.0 kW
20
90.0 kW
07
0h1C07
Base
frequency
M2-Base
Freq
30.00-
400.00(Hz)
60.00
X/A
O
I
p.218
08
0h1C08
Control mode
M2-Ctrl
Mode
0
V/F
0:V/F
X/A
O
I
p.218
2
Slip
Compen
4
IM
Sensorles
s
6
PM
Sensorless
10
0h1C0A
Number of
motor poles
M2-Pole
Num
2-48
Depen
dent
on
motor
setting
s
X/A
O
I
p.218
11
0h1C0B
Rated slip
speed
M2-Rated
Slip
0-3000(rpm)
X/A
O
I
p.218
12
0h1C0C
Motor rated
current
M2-Rated
Curr
1.0-1000.0(A)
X/A
O
I
p.218
13
0h1C0D
Motor no-load
current
M2-Noload
Curr
0.5-1000.0(A)
X/A
O
I
p.218
14
0h1C0E
Motor rated
voltage
M2-Rated
Volt
170-480(V)
X/A
O
I
p.218
