iv
Safety Information
Do not modify the interior workings of the inverter. Doing so will void the warranty.
The inverter is designed for 3-phase motor operation. Do not use the inverter to operate a
single phase motor.
Do not place heavy objects on top of electric cables. Doing so may damage the cable
and result in an electric shock.
Note
Maximum allowed prospective short-circuit current at the input power connection is defined in
IEC 60439-1 as 100 kA. Depending on the selected MCCB, the LSLV-S100 Series is suitable for
use in circuits capable of delivering a maximum of 100 kA RMS symmetrical amperes at the
drive's maximum rated voltage. The following table shows the recommended MCCB for RMS
symmetrical amperes.
Remarque
Le courant maximum de court-circuit présu autori au connecteur d’alimentation électrique
est défini dans la norme IEC 60439-1 comme égal à 100 kA. Selon le MCCB sélectionné, la
série LSLV-S100 peut être utilisée sur des circuits pouvant fournir un courant RMS symétrique
de 100 kA maximum en ampères à la tension nominale maximale du variateur. Le tableau
suivant indique le MCCB recommandé selon le courant RMS symétrique en ampères.
Working Voltage
UTE100(E/N)
UTS150(N/H/L)
ABS33c
ABS63c
ABS103c
240V(50/60Hz)
50/65 kA
65/100/150 kA
30 kA
35 kA
85 kA
480V(50/60Hz)
25/35 kA
35/65/100 kA
7.5 kA
10 kA
26 kA
Working
Voltage
UTS150
(N/H/L)
UTS250
(N/H/L)
UTS400
(N/H/L)
ABS103c
ABS203c
ABS403c
480V(50/60Hz)
35/65/100kA
35/65/100kA
35/65/100kA
26kA
26kA
35kA
