LSIS LSLV-S100 - Dynamic Braking Unit(DBU) and Resistors

Technical Specification
411
2.2kW(Single Phase 200V), 3.7-4.0kW(3-Phase 400V) EMC filter Type
Items
W1
W2
H1
H2
H3
D1
A
B
Φ
0022S100-1
0037S100-2
0040S100-2
0037S100-4
0040S100-4
140
(5.51)
132.2
(5.20)
128
(5.04)
120.7
(4.75)
3.7
(0.15)
145
(5.71)
3.9
(0.15)
4.4
(0.17)
4.5
(0.18)
0022S100-1,
0037S100-4,
0040S100-4
EMC Type
140
(5.51)
132
(5.20)
180
(7.09)
170
(6.69)
5
(0.20)
140
(5.51)
4
(0.16)
4
(0.16)
4.2
(0.17)
Units: mm (inches)
