LSIS LSLV-S100 User Manual

61
Learning to Perform Basic Operations
No.
Name
Display
Description
A
Application option operation command
R
Internal 485 operation command
T
Terminal operation command
Frequency
commands
K
Keypad frequency command
V
V1 input frequency command
P
Pulse input frequency command
U
Frequency command for UP operation (Up - Down
operation)
D
Frequency command for DOWN operation (Up -
Down operation)
S
Frequency command for STOP operation (Up -
Down operation)
O
FBus Option frequency command
J
Jog frequency command
R
Int 485 frequency command
1 ~9, A~F
Multi-step frequency command
3
Multi-
functional key
settings
JOG Key
Keypad JOG operation mode
Local/Remote
Able to select either local or remote operation
UserGrpSelKey
Register or delete user group parameters in
parameter mode
4
Inverter
operation
status
STP
Motor stopped
FWD
Operating in forward direction
REV
Operating in reverse direction
DC
DC output
WAN
Warning
STL
Stall
SPS
Speed Search
OSS
S/W overcurrent protective function is on
OSH
H/W overcurrent protective function is on
TUN
Auto Tuning
