Learning to Perform Basic Operations
The following table lists the 5 display modes used to control the inverter functions.
Displays the inverter’s operation status information. In
this mode, information including the inverter’s frequency
reference, operation frequency, output current, and
voltage may be monitored.
Used to configure the functions required to operate the
inverter. These functions are divided into 14 groups
based on purpose and complexity.
Used to monitor the inverter’s fault trip information,
including the previous fault trip history.
When a fault trip occurs during inverter operation, the
operation frequency, output current, and output voltage of
the inverter at the time of the fault may be monitored.
This mode is not displayed if the inverter is not at fault
and fault trip history does not exist.
Used to configure the inverter features that are not
directly related to the operation of the inverter. The
settings you can configure in the Config mode include
keypad display language options, monitor mode
environment settings, communication module display
settings, and parameter duplication and initialization.
