Learning to Perform Basic Operations
3.2.3.2 30-75kW Models
Parameter mode and Config mode allow direct jumps to specific codes. The code used for
this feature is called the Jump Code. The Jump Code is the first code of each mode. The
Jump Code feature is convenient when navigating for a code in a function group that has
many codes.
The following example shows how to navigate directly to code DRV- 09 from the initial code
(DRV-00 Jump Code) in the Drive group.
• The Drive group (DRV) is displayed in Parameter
mode. Make sure that the fist code in the Drive group
(DRV 00 Jump Code) is currently selected.
• Press the [PROG/ENT] key.
• The Code input screen is displayed and the cursor
flashes. A flashing cursor indicates that it is waiting for
user input.
• Press the [▲] key to increase the number to 9, and
then press the [PROG/ENT] key.
• DRV-09 (Control Mode) is displayed.
• Press the [ESC] key to go back to the initial code of
the Drive group.
