3.6.11 Replacing CR Return Pulley Assy 106
3.6 Replacing Y Rail part VJ628XE-M-00
8 Assemble Return Pulley Axis to New CR
Return Pulley Assy.
A : Return Pulley Axis
B : CR Return Pulley
C : Bearing
9 To reassemble unit, reverse the removal
procedure.
After installing CR Return pulley, move
Carriage with your hand from side to side,
and check if CR belt is equally balanced
on the pulley center section of CR Motor.
The thinner side of
the axis at the bottom
Material notation (POM) at the top
Make sure that the bearing
does not proture from CR
Return Pulley when installed
