5.3.2 Diagnosis Items in Self-Diagnosis Menu
The self-diagnosis menu includes the following diagnosis items.
Diagnosis item Contents Reference
Test Display the following items on Operation
panel.
Memory size
Firmware version
Panel
Sensor
Encoder
Fan
History
Head waveform
Time Check
"5.4 Test Menu
InkCharge Performs initial cleaning of Print head and ink
charging.
"5.5 Ink Charging
Menu
Adjustment Head Adjustment, Sensor Position,
Sensitivity adjustment
"5.6 Adjustment
Menu
Cleaning Performs cleaning of Print head.
"5.7 Cleaning Menu
Print Performs printing of the following items:
Adjustment pattern ALL
Parameter ALL
Error history
S/C Log
"5.8 Sample printing
Menu
Parameter Performs the setting and initialization of the
adjustment parameter.
"5.9 Parameter
Menu
Servo Performs setting for Servo motor.
"5.10 Servo Setting
Menu
Endurance Performs endurance running of the printer
mechanism.
"5.11 Endurance
Running Menu
MediaFeed The media is fed forward and backward, and
then cut.
"5.12 Media Feed
Menu
MediaInitial Performs media detection setting.
"5.13 Media Initial
Menu
Heater The status of the sensors related to the
heater is displayed on the panel.
"5.14 Heater
SpeedMode Set the print speed for user mode.
"5.15 Speed mode
>!@
>@
㹁㹦㹣㹡㹩㸯㸯㸸㹆㹣㹟㹲㹣㹰
㹁㹦㹣㹡㹩ࠉ㸯㸸㹒㹣㹱㹲
㹁㹦㹣㹡㹩ࠉ㸰㸸㹇㹬㹩㹁㹦㹟㹰㹥㹣
㹁㹦㹣㹡㹩ࠉ㸱㸸㸿㹢㹨㹳㹱㹲㹫㹣㹬㹲
㹁㹦㹣㹡㹩ࠉ㸳㸸㹎㹰㹧㹬㹲
㹁㹦㹣㹡㹩ࠉ㸲㸸㹁㹪㹣㹟㹬㹧㹬㹥
㹁㹦㹣㹡㹩ࠉ㸵㸸㹑㹣㹰㹴㹭
㹁㹦㹣㹡㹩ࠉ㸶㸸㹃㹬㹢㹳㹰㹟㹬㹡㹣
㹁㹦㹣㹡㹩ࠉ㸷㸸㹋㹣㹢㹧㹟㹄㹣㹣㹢
㹁㹦㹣㹡㹩㸯㸮㸸㹎㹟㹮㹣㹰㹇㹬㹧㹲㹧㹟㹪
㹁㹦㹣㹡㹩ࠉ㸴㸸㹎㹟㹰㹟㹫㹣㹲㹣㹰
[Enter]
[Cancel]
Test Menu
InkCharge Menu
Adjustment Menu
Cleaning Menu
Print Menu
Parameter Menu
Servo Menu
Endurance Menu
PaperFeed Menu
PaperInitial Menu
Heater Menu
㹁㹦㹣㹡㹩㸯㸰㸸㹑㹮㹣㹣㹢㹋㹭㹢㹣
SpeedMode Menu
