7.4 Jigs and Tools
This section provides lists of jigs and tools required for service operations.
7.4.1 Required Tools
(1) Tools for Part Replacement
No. Name Part number Remarks
1 Phillips screwdriver No.2 Generic product More than 250 mm shaft length is
recommended.
2 Phillips screwdriver No.2 Generic product Less than 50 mm shaft length is
recommended.
3 Phillips screwdriver No.1 Generic product -
4 slotted screwdriver Generic product -
5 slotted screwdriver
（precision）
Generic product -
6 Box driver Generic product For replacing CR board assemblies
7 Flat-shaped ratchet
driver
Generic product -
8 Long-nose pliers Generic product -
9 Tweezers Generic product -
10 Hex wrench (2.5 mm) Generic product -
11
Hex wrench (2.5mm）
Generic product
For screws retaining Head base, with shaft
length of 150mm or longer and not L-
shaped
12 Hex wrench (1.5mm) Generic product -
13 E ring holder (E-2.5) Generic product -
14 E ring holder (E-6) Generic product -
15 Penlight Generic product -
16 tube cutter Generic product For replacing Valve Heads or Ink
tubes
17 Measure Generic product For replacing Steel belt, longer than
3m
18 Loupe Generic product For confirming adjustment pattern
19 magic marker Generic product -
20 plastic bag Generic product -
21 Thread Locker Generic product Three bond 1401
22 waste cloth Generic product -
23 acetate tape Generic product
width: 18mm、30mm
No. Name Part number Remarks
