4-50 Operation
10. If your process requires needle heat or tooling heat, verify the heater temperature.
a. In the Production Window, click on
Run and then on Run Production.
 The Run Window opens (Figure 4-49).
b. Select the Temperature tab.
 If your program requires both needle heat and tooling heat, there will be two
temperature tabs.
c. Verify the heater(s) has reached set point temperature before running the program.
 NOTE The heater setup can be configured so that the dispensing program will
not run until the heaters have reached set point.
11. Click on
Go in the Run Window to start the production run.
12. Click on the Run Status tab in the Run Window to monitor the production run.
 Select the applicable tab to monitor temperature, vision, or other system components.
Figure 4-49 Run Window
WARNING! Press the EMO button (Figure 2-10) on the dispensing system if personnel are in
danger of injury or if system components or workpieces may be damaged.
