5-14 Calibration and Adjustment
Figure 5-15A Dispensing Head with Mechanical/Tactile Height Sensor
Figure 5-15B Probe-to-Nozzle Alignment
Figure 5-15C Probe-to-Needle Alignment
Item
Description
Item
Description
1 Nozzle 3 Height Sensor Locking Screws (2)
2
Height Sensor Probe
4
Needle
Figure 5-15 Adjusting the Height Sensor Probe
 NOTE For additional information on dispensing valve-to-height sensor offsets, See
4.9 Valve Offsets.
2
4
2
1
2
1
3
