Nordson Spectrum II Series User Manual

Calibration and Adjustment 5-23
6. Select OK.
 The Heater Parameters Window closes and you will return to the Heater Control
Window.
7. Activate the heater by double clicking the icon in the On/Off column until the heater loop
icon
turns yellow and red.
 Allow time for the heater to reach the setpoint temperature.
8. Use a thermal measuring device to measure the temperature on the heating tooling.
 If the temperature is different from the setpoint temperature, the heaters should be
calibrated as described in 5.14.2 Heater Calibration.
9. If heater calibration is required, leave the heater on. If not, double-click the Heater On/Off
icon to turn the heater off.
 The Heater On/Off icon is gray
when the heater is off.
10. Click on
Exit to exit the Heater Control Window.
11. Click on
to return to the Fluidmove Main Menu.
