Oce CS2436 - Clearing Jammed Roll Paper

Handling Paper (CS2436-6)
6. 2. 8. Handling Paper > Handling rolls >
Clearing Jammed Roll Paper
If paper from a roll becomes jammed, "Paper jam." is shown on the Display Screen of the Control Panel.
Remove the jammed paper as follows.
1.
Open the Roll Cover. Use a commercially available cutter or the like to cut the paper of the loaded roll.
Caution
･ When cutting paper, be careful to avoid injury or damage to the printer.
2. Push the Release Lever back.
3. Remove the jammed paper.
● If paper is jammed inside the Top Cover
1. Open the Top Cover and move the Carriage to the left or right side manually, away from
the jam.
