Troubleshooting (CS2436-11)
11. 8. 6.
Troubleshooting > HP-GL/2 problems >
HP-GL/2 jobs are printed 6 mm larger than specified
Cause
Corrective Action
The page size of the HP-
GL/2 print job, as created
in the source application,
is incorrect.
In the Control Panel menu, set
PageSizeProcess1
to
On
.
(See "Menu Settings (
8.2.8
).")
2]
file:///H|/ITC-dd/Projects/Ud/WFPS/oostende%205/...port/iPF750%20User%20Manual/lang/print/cp08.html (63 of 75) [4-3-2010 11:37:2
720
722
