8. 4. 1. Printer Parts > Printer Specifications >
Specifications
Important
ï½¥ This information is subject to change as the printer is updated.
ï½¥ The following values may vary depending on the operating environment.
Printer
Power supply
100–120 V AC (50/60 Hz), 220–240 V AC
(50/60 Hz)
Power consumption
During operation 140 W max.
Sleep mode
100–120 V: 5 W max.
220–240 V: 6 W max.
Off
1 W max. (
*1)
Operating noise (
*2)
During operation (sound
pressure level/LWAd)
Approx. 50 dB (A) (6.6 bels)
Standby 35 dB (A) max.
Operating environment
Temperature 15–30°C (59–86°F)
Humidity 10–80%, non-condensing
Dimensions (W × D × H)
Printer and Stand (with
Output Stacker open)
1,304×870×1,062 mm (51.3×34.3×41.8 in)
Weight
Printer and Stand (not
including the Printhead and
ink tanks)
Approx. 62.9 kg (138.7 lb)
Space for installation (W × D
× H)
Printer only 1,704×1,470×1,362 mm (67.1×57.9×53.6 in)
Applicable standards
International Energy Star Program, Law on
Promoting Green Purchasing, Eco Mark, GPN,
RoHS, Eco Declaration, WEEE, U.S.
presidential directives
*1: The printer uses a trace amount of power even when turned off. To stop all power consumption, turn off
the printer and unplug the power cord.
*2: Calculation based on ISO 7779. Operating conditions: On the Main sheet of the printer driver, Media
Type >Plain Paper, Advanced Settings >Print Priority >Line Drawing/Text, and Print Quality
>Standard.
Printing performance
Print method Bubblejet
Maximum resolution
2400 dpi horizontally (
*1) × 1200 dpi vertically
Printhead 0029951267
Number of nozzles MBK: 5,120; others: 2,560 per color
*1: Prints with a minimum 1/2400 inch dot pitch between ink droplets.
Interface
USB 2.0 (*1)
Format Internal port
Mode Full-speed (12 Mbps), high-speed (480 Mbps), bulk transfer
Connector Series B (4-pin)
Ethernet
Format Internal port
