6. 2. 2. Handling Paper > Handling rolls >
Loading Rolls in the Printer
Follow these steps to load rolls in the printer.
Note
ï½¥ Before loading rolls, make sure the printer is clean inside the Top Cover and around the
Ejection Guide. If these areas are dirty, we recommend cleaning them in advance. (See
"Cleaning Inside the Top Cover (
10.4.2).")
1. Press the Load button.
2. Press or to select Load Roll Paper, and then press the OK button.
Note
ï½¥ If any paper has been advanced that will not be used, a message is shown
requesting you to remove it.
Press
or to select "Yes", and then press the OK button. Remove the paper
and go to the next step.
3. Positioning your hands as shown, open the Roll Cover.
4. Holding the Roll Holder flange (a), rest the Roll Holder shaft on the Roll Ledge (b).
To Next Page
