Troubleshooting (CS2436-11)
11. 8. 5.
Troubleshooting > HP-GL/2 problems >
Printed colors of lines are inaccurate during HP-GL/2
printing
Cause
Corrective Action
AdjustFaintLines
is
On
in the
Control Panel menu.
Setting
AdjustFaintLines
to
Off
in
the Control Panel menu may help
produce the expected results.
However, lines in some colors may
appear broken.
2]
file:///H|/ITC-dd/Projects/Ud/WFPS/oostende%205/...port/iPF750%20User%20Manual/lang/print/cp08.html (62 of 75) [4-3-2010 11:37:2
719
721
Table of Contents
1. Basic Printing Workflow
2
Default Chapter
2
Basic Printing Workflow
2
Printing Options Using Rolls and Sheets
3
Loading and Printing on Rolls
5
Loading and Printing on Sheets
9
Printing in Windows
12
Printing in Mac os X
14
Registering the Printer
14
Specifying Paper in the Printer Driver (Windows)
16
Specifying Paper in the Printer Driver (Mac os X)
18
Canceling Print Jobs from the Control Panel
22
Canceling Print Jobs from Windows
23
Canceling Print Jobs from Mac os X
25
Pausing Printing
28
Table of Contents
2
1. 1. Printing Procedure
3
1. 2. Canceling Print Jobs
22
2. Working with Various Print Jobs
29
Default Chapter
29
Working with Various Print Jobs
29
Printing Cad Drawings
30
Printing Line Drawings and Text
31
Printing Line Drawings and Text (Windows)
33
Printing Line Drawings and Text (Mac os X)
36
Printing Photos and Images
41
Printing Photos and Images (Windows)
43
Printing Photos and Images (Mac os X)
46
Easy Settings
51
Printing Office Documents (Windows)
53
Printing Office Documents (Mac os X)
56
Printing Office Documents
51
Enhanced Printing Options
60
Table of Contents
61
Adjusting the Color in the Printer Driver
63
Color Adjustment
63
Fine-Tuning Colors of Photos and Images (Windows)
67
Fine-Tuning Colors of Photos and Images (Mac os X)
71
Print Quality
76
Enhancing Printing Quality
78
Choosing the Document Type and Printing Conditions (Windows)
80
Choosing a Paper for Printing
87
Changing the Type of Paper
88
Specifying Paper in the Printer Driver
91
Resizing Originals to Match the Paper Size
98
Resizing Originals to Match the Paper Size (Windows)
99
Resizing Originals to Match the Paper Size (Mac os X)
101
Resizing Originals to Fit the Roll Width
106
Resizing Originals to Fit the Roll Width (Windows)
107
Resizing Originals to Fit the Roll Width (Mac os X)
110
Resizing Originals by Entering a Scaling Value
114
Resizing Originals by Entering a Scaling Value (Windows)
115
Resizing Originals by Entering a Scaling Value (Mac os X)
118
Printing on Oversized Paper
123
Printing at Full Size (Windows)
125
Printing at Full Size (Mac os X)
127
Borderless Printing at Actual Size
132
Borderless Printing on Paper of Equivalent Size
144
Borderless Printing by Resizing Originals to Match the Paper Size (Windows)
146
Borderless Printing by Resizing Originals to Match the Paper Size (Mac os X)
150
Borderless Printing by Resizing Originals to Fit the Roll Width
156
Mac os X
162
Creating the Banner in the Application
183
Printing the Banner
184
Printing on Non-Standard Paper Sizes
195
Printing on Non-Standard Paper Sizes (Windows)
196
Printing on Non-Standard Paper Sizes (Mac os X)
202
Printing Multiple Pages Per Sheet
208
Printing Multiple Pages Per Sheet (Windows)
209
Printing Multiple Pages Per Sheet (Mac os X)
212
Printing Posters in Sections
218
Printing Large Posters (Windows)
219
Printing Originals Centered on Rolls
222
Printing Originals Centered on Rolls (Windows)
223
Printing Originals Centered on Rolls (Mac os X)
226
Printing Originals Centered on Sheets
231
Printing Originals Centered on Sheets (Windows)
232
Printing Originals Centered on Sheets (Mac os X)
235
Conserving Roll Paper by Rotating Originals 90 Degrees
239
Printing with Watermarks
258
Printing with Watermarks- Copy, File Copy, and so on
260
Making the Original Orientation Match the Paper Orientation
263
Using Favorites
271
Using Favorites (Windows)
272
Using Favorites (Mac os X)
275
Cutting Roll Paper after Printing (Windows)
277
Cutting Roll Paper after Printing (Mac os X)
279
4. Windows Software
283
Default Chapter
283
Windows Software
283
Printer Driver Settings
285
Confirming Print Settings
291
Accessing the Printer Driver Dialog Box from Applications (4.1.6)
296
Accessing the Printer Driver Dialog Box from the Operating System Menu (4.1.7)
298
Main Sheet (4.1.8)
301
Status Monitor
302
Advanced Settings
302
View Settings
303
Color Mode
304
Color Settings
305
Paper Information on Printer Dialog Box
306
Drying Time
307
Paper Detailed Settings Dialog Box (4.1.10)
307
View Settings Dialog Box for the Printing Application (4.1.11)
309
Color Adjustment Sheet: Color (4.1.12)
311
Driver Matching Mode
314
Matching Sheet (4.1.14)
314
Matching Method
315
Color Adjustment Sheet: Monochrome (4.1.15)
317
Page Setup Sheet (4.1.17)
320
Paper Size
321
Paper Size Options Dialog Box (4.1.18)
324
Layout Sheet (4.1.19)
326
Edit Watermark
327
Reverse Order
327
Special Settings
327
Special Settings Dialog Box (4.1.21)
329
Favorites Sheet (4.1.22)
331
Settings Details
331
Utility Sheet (4.1.23)
334
The Features of Status Monitor
335
Job Management Using Status Monitor
338
Accounting Manager
340
Launching the Accounting Manager
341
Accounting Manager Main Window
342
Title Bar
342
Job List Area
343
Totals Area
344
Status Bar
345
Accounting Manager Basic Procedures
346
Configuring Unit Costs in Accounting Manager
347
Setting the Unit Cost for Ink
348
Setting the Unit Cost for Paper
350
Setting the Unit Cost for Items Other than Ink and Paper
352
Paper Length
355
Paper Width
355
Automatically Acquiring Print Job Logs at Regular Intervals
356
Canceling Regular Print Job Log Acquisition
357
Switching between Displaying Jobs on Printer and Regularly Acquired Jobs
358
Exporting Print Job Data as a Csv File
359
Showing Job Properties
360
Showing, Saving and Loading Selected Unit Cost Data
361
Showing the Total Amount of Ink and Paper Consumed
362
Device Setup Utility
363
Mac os X Software
368
Accessing the Printer Driver Dialog Box from Applications (5.1.6)
379
Main Pane (5.1.7)
381
Unidirectional Printing
384
Paper Detailed Settings Dialog Box (5.1.9)
386
View Settings Dialog Box for the Printing Application (5.1.10)
388
Color Settings Pane: Color (5.1.11)
389
Matching Pane
390
Color Settings Pane: Monochrome (5.1.13)
393
Page Setup Pane (5.1.15)
396
Utility Pane (5.1.16)
398
Additional Settings Pane (5.1.17)
399
Support Information
400
Support Pane (5.1.18)
400
The Features of Printmonitor
401
Job Management Using Printmonitor
403
Printing Held Jobs
404
6. Handling Paper
406
Handling Paper
406
Types of Paper
407
Paper Sizes
408
Attaching the Roll Holder to Rolls
411
Loading Rolls in the Printer
415
Specifying the Paper Length
421
Printing from a Desired Starting Point
422
Removing the Roll from the Printer
425
Removing the Roll Holder from Rolls
428
Clearing Jammed Roll Paper
430
Feeding Roll Paper Manually
436
Keeping Track of the Amount of Roll Paper Left
437
Specifying the Ink Drying Time for Rolls
438
Specifying the Cutting Method for Rolls
442
Cutting the Leading Edge of Roll Paper Automatically
447
Reducing Dust from Cutting Rolls
449
Roll Holder Set
450
Loading Sheets in the Printer
451
Removing Sheets
459
Clearing a Jammed Sheet
461
Using the Output Stacker
466
Note Regarding the Extended Position
467
Adjusting the Printhead
469
Adjustments for Better Print Quality
469
Automatic Adjustment to Straighten Lines and Colors (Head Posi. Adj)
471
Manual Adjustment to Straighten Lines and Colors (Head Posi. Adj)
474
Adjusting Line Misalignment (Head Inc. Adj)
477
Adjusting the Feed Amount
483
Selecting a Feed Amount Adjustment Method (Feed Priority)
484
Manual Banding Adjustment (Adj. Quality)
486
Fine-Tuning the Paper Feed Amount (Adj. Fine Feed)
489
Adjusting Line Length (Adjust Length)
490
Adjusting the Vacuum Strength (Vacuumstrngth)
493
8. Printer Parts
494
Default Chapter
494
Printer Parts
494
Top Cover (Inside)
498
Roll Cover (Inside)
499
Ink Tank Cover (Inside)
501
Control Panel
503
Turning the Printer on and off
507
Control Panel Display
509
Mode Transition
510
How to View Instructions with Navigate
512
Printer Menu Operations
513
Menu Operations
514
Menu Structure
517
Menu Settings
526
Menu Settings (During Printing)
537
Status Print
539
Printing Interface Setting Reports
541
Checking Instructions During Printer Operations
545
Specifications
547
Print Area
550
9. Network Setting
551
Network Setting
551
Network Environment
552
System Requirements
552
Configuring the Ip Address on the Printer
555
Configuring the Ip Address Using the Printer Control Panel
558
Configuring the Ip Address Using Arp and Ping Commands
560
Configuring Tcp/Ipv6 Network Settings
562
Using Remoteui
563
Configuring the Printer's Tcp/Ip Network Settings
564
Specifying Printer-Related Information
575
Configuring the Communication Mode Manually
577
Email Notification When Printing Is Finished or Errors Occur
579
Initializing the Network Settings
580
Configuring the Printer Driver Destination
581
Sharing the Printer in Windows
582
Specifying the Printer's Frame Type
588
Specifying Netware Print Services
591
Specifying Netware Protocols
594
Configuring Netware Network Settings
596
Configuring the Destination for Appletalk Networks
603
Configuring the Destination in Tcp/Ip Networks
606
Configuring the Destination for Bonjour Network
609
10. Maintenance
611
Ink Tanks
612
Replacing Ink Tanks
613
Install the Ink Tanks
616
Checking Ink Tank Levels
619
When to Replace Ink Tanks
621
Checking for Nozzle Clogging
623
Cleaning the Printhead
625
Replacing the Printhead
627
Replace the Printhead
628
Maintenance Cartridge
635
Replacing the Maintenance Cartridge
636
Replace the Maintenance Cartridge
637
Checking the Remaining Maintenance Cartridge Capacity
642
When to Replace the Maintenance Cartridge
643
Display Screen
643
Cleaning the Printer Exterior
645
Cleaning Inside the Top Cover
646
Preparing to Transfer the Printer
653
Remove Paper
653
Pack the Printer
656
Updating the Firmware
658
Confirming the Firmware Version
658
11. Troubleshooting
659
Frequently Asked Questions
661
Roll Paper Cannot be Inserted into the Paper Feed Slot
676
Cannot Load Sheets
677
Paper Is Not Cut Straight
678
Paper Is Not Cut
679
Depression on the Leading Edge Is Left
680
The Size of Clear Film Cannot be Detected
681
Roll Paper Is Continuously Ejected
682
The Printer Does Not Respond Even if Print Jobs Are Sent
684
Ink Filling.. Is Displayed
685
The Display Screen Indicates Agitating
686
An Error Message Is Shown on the Display Screen
687
The Printer Ejects Blank, Unprinted Paper
688
Printing Is Faint
690
Paper Rubs against the Printhead
691
The Edges of the Paper Are Dirty
693
The Surface of the Paper Is Dirty
695
The Back Side of the Paper Is Dirty
696
Printed Colors Are Inaccurate
697
Banding in Different Colors Occurs
698
Colors in Printed Images Are Uneven
700
Image Edges Are Blurred or White Banding Occurs
702
The Contrast Becomes Uneven During Printing
703
Images Are Printed Crooked
705
Documents Are Printed in Monochrome
706
Line Thickness Is Not Uniform
707
Lines Are Misaligned
708
Cannot Connect the Printer to the Network
710
Cannot Print over a Tcp/Ip Network
711
Cannot Print over a Netware Network
712
Cannot Print over Appletalk or Bonjour Networks
713
Removing Installed Printer Drivers
714
With Hp-Gl/2, Printing Is Misaligned
716
Lines or Images Are Missing in Printed Hp-Gl/2 Jobs
717
Lines Are Printed too Thick or Thin in Hp-Gl/2 Print Jobs
718
Hp-Gl/2 Jobs Are Printed in Monochrome (or Color)
719
Hp-Gl/2 Jobs Are Printed 6 MM Larger than Specified
721
Hp-Gl/2 Printing Takes a Long Time
723
Replotting with Hp-Gl/2 Jobs Is Not Possible
724
The Printer Does Not Go on
726
If the Printer Makes a Strange Sound
727
The Printer Consumes a Lot of Ink
730
Ink Level Detection
731
Releasing Ink Level Detection
731
Error Message
734
Error Messages
734
Messages Regarding Paper
735
Messages Regarding Ink
736
Messages Regarding Printheads
736
Messages Regarding Printing or Adjustment
736
Messages Regarding the Maintenance Cartridge
736
Other Messages
737
Borderless Printng Not Possible
738
Cannot Adjust Paper Feed
740
Cannot Adjust Printhead
741
Cannot Detect Papr
742
Check Printed Document
743
Close Ink Tank Cover
744
Do Not Pull out Ink Tank
745
End of Paper Feed
746
Error in Cutter Position
748
Execute Printhead Cleaning
749
Ink Insufficient
755
Ink Tank Is Empty
756
Insert the Maintenance Cartridge
757
Insufficient Paper for Job
758
Maintenance Cartridge Full
760
Maintenance Cartridge Problem
761
Mediatype Mismatch
762
No Ink Left
764
No Ink Tank Loaded
765
No Maintenance Cartridge Capacity
766
Not Much Ink Is Left
768
Paper Cutting Failed
769
Paper Is Crooked
771
Paper Jam
773
Paper Not Aligned with Right Guide
774
Paper Position Not Suitable for Borderless Printing
775
Paper Size Not Detected
776
Paprwidth Mismatch
779
Parts Replacement Time Has Passed
780
Prepare for Parts Replacement
781
Printhead Error
782
Rel Lever Is in Wrong Position
784
Remaining Level of the Ink Cannot be Correctly Detected
785
Roll Paper Is Not Securely in Contact with Roll Holder
786
Roll Printing Is Selected
788
Sheet Printing Is Selected
789
The Paper Is too Small
790
The Roll Is Empty
793
This Paper Cannot be Used
794
Top Cover Is Open
796
Unable to Detect Ink Level Correctly
797
Unknown File
798
Wrong Ink Tank
799
Wrong Maintenance Cartridge
800
Wrong Printhead
801
How to Use this Manual
867
About this User Manual
868
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Oce CS2436 and is the answer not in the manual?
Ask a question
Oce CS2436 Specifications
General
Brand
Oce
Model
CS2436
Category
Printer
Language
English
Related product manuals
Oce TDS400-CS
326 pages
Oce ColorWave 650
452 pages
Oce 9300
121 pages
Oce PlotWave 300
340 pages
Oce PlotWave 360
384 pages
Oce PlotWave 340
384 pages
Oce plotwave 345
300 pages
Oce Arizona 550 GT
273 pages
Oce Arizona 318 GL
224 pages
Oce VarioPrint 6160
82 pages
Oce Arizona 6160 XTS
180 pages
Oce VarioPrint 6180 Titan
102 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
