6. 3. 6. Handling Paper > Handling sheets >
Clearing Jammed Paper (Paper Feed Slot)
Follow these steps to remove any scraps left in the Paper Feed Slot after you clear jammed sheets or roll paper.
1. Turn the printer off. (See "Turning the Printer On and Off (8.2.2).")
2. Push the Release Lever back.
3. Positioning your hands as shown, open the Roll Cover.
4. Fold an A4 sheet lengthwise four times and insert it through the gap of the Paper Feed Slot. Push the
scrap out toward the Platen.
To Next Page
