Page #21 background imageLoading...
Page #21 background image
xxi
Fuse Sizes 6
6 Fuse Sizes
The inverter shall be connected with a UL Listed Cartridge Nonrenewable
fuse, rated 600Vac with the current ratings as shown in the table below.
Inverter Model Type Rating
MX2-AB001,
MX2-AB002,
MX2-AB004
Class J 10A, AIC 200kA
MX2-AB007 15A, AIC 200kA
MX2-AB015
MX2-AB022
30A, AIC 200kA
MX2-A2001,
MX2-A2002,
MX2-A2004,
10A, AIC 200kA
MX2-A2007,
MX2-A2015
15A, AIC 200kA
MX2-A2022 20A, AIC 200kA
MX2-A2037, 30A, AIC 200kA
MX2-A2055
MX2-A2075
40A, AIC 200kA
MX2-A2110
MX2-A2150
80A, AIC 200kA
MX2-A4004,
MX2-A4007,
MX2-A4015,
MX2-A4022
10A, AIC 200kA
MX2-A4030,
MX2-A4040,
15A, AIC 200kA
MX2-A4055
MX2-A4075
20A, AIC 200kA
MX2-A4110
MX2-A4150
40A, AIC 200kA
