Omron MX2 User Manual

122
"B" Group: Fine Tuning Functions Section 3-6
Note When 01 is set on b180, and key is pressed, initialization starts immedi-
ately and there is not any way to restore the previous parameter setting. MX2
doesn't have a method to trigger the initialization by key action as others
Omron inverter models have.
Stop Mode/Restart Mode Configuration: B091/B088 – You can configure
how the inverter performs a standard stop (each time Run FWD and REV sig-
nals turn OFF). Setting B091 determines whether the inverter will control the
deceleration, or whether it will perform a free-run stop (coast to a stop). When
using the free-run stop selection, it is imperative to also configure how you
want the inverter to resume control of motor speed. Setting B088 determines
whether the inverter will ensure the motor always resumes at 0 Hz, or whether
the motor resumes from its current coasting speed (also called active fre-
quency matching). The run command may turn OFF briefly, allowing the
motor to coast to a slower speed from which normal operation can resume.
b094 Initialization target data Select initialized parameters, four
option codes:
00 All parameters
01 All parameters except in/out-
put terminals and communi-
cation.
02 Only registered parameters
in Uxxx.
03 All parameters except regis-
tered parameters in Uxxx and
b037.
8 00
b095 Dynamic braking control (BRD)
selection
Three option codes:
00 Disable
01 Enable during run only
02 Enable always
8 00
b096 BRD activation level Range is:
330 to 380 V (200 V class)
660 to 760 V (400 V class)
8 360/720 V
b097 BRD resistor value Ohmic value of the braking resis-
tor connected to the drive
Min. Resistance to 600.0 Ω
8 Specified by
the inverter
capacity
Ω
b166 Data Read/Write select Controls the Read and Write pro-
tection
00 R/W OK
01 Protected
8 00
b180 Initialization trigger
(*)
This is to perform initialization by
parameter input with b084, b085
and b094. Two option codes:
00 Initialization disable
01 Perform initialization
8 00
"B" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
