Omron MX2 - List of Registers; List of Registers (Function Modes)

288
ModBus Data Listing Section B-4
(iv) List of registers
(v) List of registers (function modes)
Parameter group A
After changing the setting, keep the time 40 ms or longer before actually give run command
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1103h Acceleration time (1) F002 (high) R/W 1 to 360000 0.01 [sec.]
1104h F002 (low)
1105h Deceleration time (1) F003 (high) R/W 1 to 360000 0.01 [sec.]
1106h F003 (low)
1107h Keypad Run key routing F004 R/W 0 (forward rotation), 1 (reverse rotation) –
1108h to
1200h
Unused – – Inaccessible –
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1201h Frequency source A001 R/W 0 (keypad potentiometer), 1 (control
circuit terminal block), 2 (digital opera-
tor), 3 (Modbus), 4 (option ), 6 (pulse
train input), 7 (easy sequence),
10 (operation function result)
–
1202h Run command source (*) A002 R/W 1 (control circuit terminal block), 2 (digi-
tal operator), 3 (Modbus), 4 (option)
–
1203h Base frequency A003 R/W 300 to "maximum frequency" 0.1 [Hz]
1204h Maximum frequency A004 R/W 300 to 4000 (10000) 0.1 [Hz]
1205h [AT] selection A005 R/W 0 (switching between O and OI termi-
nals), 2 (switching between O terminal
and keypad potentiometer), 3 (switching
between OI terminal and keypad poten-
tiometer)
–
1206h to
120Ah
(Reserved) – – – –
120Bh [O] input active range start fre-
quency
A011 (high) R/W 0 to 40000(100000) 0.01 [Hz]
120Ch A011 (low)
120Dh [O] input active range end fre-
quency
A012 (high) R/W 0 to 40000(100000) 0.01 [Hz]
120Eh A012 (low)
120Fh [O] input active range start volt-
age
A013 R/W 0 to "[O]-[L] input active range end
voltage"
1 [%]
1210h [O] input active range end volt-
age
A014 R/W "[O]-[L] input active range start voltage"
to 100
1 [%]
1211h [O] input start frequency select A015 R/W 0 (external start frequency), 1 (0 Hz) –
1212h Analog input filter. A016 R/W 1 to 30 or 31 (500 ms filter ±0.1 Hz
with hysteresis)
1
1213h EzSQ selection A017 R/W 0 (disabling), 1 (PRG terminal) ,
2 (Always)
–
1214h (Reserved) – – – –
1215h Multi speed operation selection A019 R/W 0 (binary), 1 (bit) –
1216h Multi-speed freq. 0 A020 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1217h A020 (low) R/W
1218h Multi-speed freq. 1 A021 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1219h A021 (low) R/W
121Ah Multi-speed freq. 2 A022 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
121Bh A022 (low) R/W
121Ch Multi-speed freq. 3 A023 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
121Dh A023 (low) R/W
121Eh Multi-speed freq. 4 A024 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
121Fh A024 (low) R/W
1220h Multi-speed freq. 5 A025 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1221h A025 (low) R/W
1222h Multi-speed freq. 6 A026 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1223h A026 (low) R/W
1224h Multi-speed freq. 7 A027 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
