ModBus Data Listing Section B-4
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1226h Multi-speed freq. 8 A028 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1227h A028 (low) R/W
1228h Multi-speed freq. 9 A029 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1229h A029 (low) R/W
122Ah Multi-speed freq. 10 A030 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
122Bh A030 (low) R/W
122Ch Multi-speed freq. 11 A031 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
122Dh A031 (low) R/W
122Eh Multi-speed freq. 12 A032 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
122Fh A032 (low) R/W
1230h Multi-speed freq. 13 A033 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1231h A033 (low) R/W
1232h Multi-speed freq. 14 A034 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1233h A034 (low) R/W
1234h Multi-speed freq. 15 A035 (high) R/W 0 or "start frequency" to "maximum
frequency"
0.01 [Hz]
1235h A035 (low) R/W
1236h (Reserved) – – – –
1237h (Reserved) – – – –
1238h Jog frequency A038 R/W 0.0, "Start frequency" to 999(10000) 0.01 [Hz]
1239h Jog stop mode A039 R/W 0 (free-running after jogging stops
[disabled during operation])
1 (deceleration and stop after jogging
stops [disabled during operation])
2 (DC braking after jogging stops [dis-
abled during operation])
3 (free-running after jogging stops
[enabled during operation])
4 (deceleration and stop after jogging
stops [enabled during operation])
5 (DC braking after jogging stops
[enabled during operation])
123Ah (Reserved) – – – –
123Bh Torque boost method selection A041 R/W 0 (manual torque boost),
1 (automatic torque boost)
–
123Ch Manual torque boost value A042 R/W 0 to 200 0.1 [%]
123Dh Manual torque boost frequency A043 R/W 0 to 500 0.1 [%]
123Eh V/F characteristic curve selec-
tion, 1st motor
A044 R/W 0 (VC), 1 (VP), 2 (free V/f),
3 (sensorless vector control),
–
123Fh V/f gain A045 R/W 20 to 100 1 [%]
1240h Voltage compensation gain set-
ting for automatic torque boost,
1st motor
A046 R/W 0 to 255 1 [%]
1241h Slippage compensation gain set-
ting for automatic torque boost,
1st motor
A047 R/W 0 to 255 1 [%]
1242h
to1244h
(Reserved) – – – –
1245h DC braking enable A051 R/W 0 (disabling), 1 (enabling),
2 (output freq < [A052])
–
1246h DC braking frequency A052 R/W 0 to 6000 0.01 [Hz]
1247h DC braking wait time A053 R/W 0 to 50 0.1 [sec.]
1248h DC braking force during deceler-
ation
A054 R/W 0 to 100 1 [%]
1249h DC braking time for deceleration A055 R/W 0 to 600 0.1 [sec.]
124Ah DC braking/edge or level detec-
tion for [DB] input
A056 R/W 0 (edge operation),
1 (level operation)
–
124Bh DC braking force for starting A057 R/W 0 to 100 1 [%]
124Ch DC braking time for starting A058 R/W 0 to 600 0.1 [sec.]
124Dh DC braking carrier frequency
setting
A059 R/W 20 to 150 0.1 [kHz]
124Eh (Reserved) – – – –
