180
Using Intelligent Input Terminals Section 4-5
4-5-2 Set Second Motor, Special Set
If you assign the [SET] function to an intelligent input terminal, you can select
between two sets of motor parameters. The second parameters store an alter-
nate set of motor characteristics. When the terminal [SET] is turned ON, the
inverter will use the second set of parameters to generate the frequency out-
put to the motor. When changing the state of the [SET] input terminal, the
change will not take effect until the inverter is stopped.
When you turn ON the [SET] input, the inverter operates per the second set of
parameters. When the terminal is turned OFF, the output function returns to
the original settings (first set of motor parameters). Refer to "Configuring the
Inverter for Multiple Motors" on page 148 for details.
Parameters SET Parameters SET
Stop Run Stop Run
F002/F202 A093/A293 9 –
F003/F203 9 – A094/A294 9 –
A001/A201 9 – A095/A295 9 –
A002/A202 9 – A096/A296 9 –
A003/A203 9 – b012/b212 9 –
A004/A204 9 – b013/b213 9 –
A020/A220 9 – b021/b221 9 –
A041/A241 9 – b022/b222 9 –
A042/A242 9 – b023/b223 9 –
A043/A243 9 – C041/C241 9 –
A044/A244 9 – H002/H202 9 –
A045/A245 9 – H003/H203 9 –
A046/A246 9 – H004/H204 9 –
A047/A247 9 – H005/H205 9 –
A061/A261 9 – H006/H206 9 –
A062/A262 9 – H020~H024/
H220~H224
9 –
A081/A281 9 – 9
A082/A282 9 – H030~H034/
H230~H234
9 –
A092/A292 9 – 9
Option
Code
Terminal
Symbol
Function
Name
State Description
08 SET Set (select)
2nc
Motor data
ON causes the inverter to use the 2nd
set of motor parameters for gener-
ating the frequency output to motor
OFF causes the inverter to use the 1st
(main) set of motor parameters for
generating the frequency output to
motor
Valid for inputs: C001~C007
Required settings: (none)
Notes:
• If the terminal state is changed while the inverter is running, the inverter continues
using the current set of parameters until the inverter is stopped.
