Omron MX2 - (III) List of Registers (Monitoring)

287
ModBus Data Listing Section B-4
(iii) List of registers (monitoring)
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1001h Output frequency monitor d001 (high) R 0 to 40000(100000) 0.01 [Hz]
1002h d001 (low)
1003h Output current monitor d002 R 0 to 65530 0.01 [A]
1004h Rotation direction minitoring d003 R 0: Stopping, 1: Forward rotation,
2: Reverse rotation
0.1 [Hz]
1005h Process variable (PV), PID feed-
back monitoring
d004 (high) R 0 to 1000000 0.1
1006h d004 (low)
1007h Intelligent input terminal status d005 R 2^0: Terminal 1 to 2^6: Terminal 7 1 bit
1008h Intelligent output terminal status d006 R 2^0: Terminal 11 to 2^1: Terminal 12/
2^2: Relay Terminal
1 bit
1009h Scaled output frequency monitor d007 (high) R 0 to 4000000(10000000) 0.01
100Ah d007 (low)
100Bh Actual-frequency monitor d008 (high) R -100000 to +100000 0.01 [Hz]
100Ch d008 (low) R
100Dh Torque command monitor d009 R -200 to +200 1 [%]
100Eh Torque bias monitor d010 R -200 to +200 1 [%]
100Fh (Reserved) – – – –
1010h Torque monitor d012 R -200 to +200 1 [%]
1011h Output voltage monitor d013 R 0 to 6000 0.1 [V]
1012h Power monitor d014 R 0 to 1000 0.1 [kW]
1013h Watt-hour monitor d015 (high) R 0 to 9999000 0.1
1014h d015 (low)
1015h Elapsed RUN time monitor d016 (high) R 0 to 999900 1 [h]
1016h d016 (low)
1017h Elapsed power-on time monitor d017 (high) R 0 to 999900 1 [h]
1018h d017 (low)
1019h Heat sink temperature monitor d018 R -200 to 1500 0.1 [?]
101Ah to
101Ch
(Reserved) – – – –
101Dh Life-check monitor d022 R 2^0: Capacitor on main circuit board
2^1: cooling-fan
1 bit
101Eh EzSQ program counter d023 R 0~1024
101Fh EzSQ program number d024 R 0~9999
1020h~1
025h
(Reserved) – – – –
1026h DC voltage monitoring (across P
and N)
d102 R 0 to 10000 0.1 [V]
1027h BRD load factor monitoring d103 R 0 to 1000 0.1 [%]
1028h Electronic thermal overload
monitoring
d104 R 0 to 1000 0.1 [%]
1029h to
102Dh
(Reserved) – – – –
102Eh User monitor 1 d025(HIGH) R -2147483647 to 2147483647 1
102Fh d025(LOW) R
1030h User monitor 2 d026(HIGH) R -2147483647 to 2147483647 1
1031h d026(LOW) R
1032h User monitor 3 d027(HIGH) R -2147483647 to 2147483647 1
1033h d027(LOW) R
1034h to
1035h
(Reserved) – – – –
1036h Position setting monitor d029(HIGH) R -268435455 to 268435455 1
1037h d029(LOW) R
1038h Position feedback monitor d030(HIGH) R -268435455 to 268435455 1
1039h d030(LOW) R
103Ah to
1056h
(reserved) – – – –
1057h Inverter mode monitor d60 R 0 (IM CT) 2(IM High Freq mode)
1(IM VT)
1058h to
1102h
unused – – Inaccessible –
