MX2 Inverter Specifications Section 1-2
1-2 MX2 Inverter Specifications
1-2-1 Model-specific tables for 200 V and 400 V class inverters
The following tables are specific to MX2 inverters for the 200 V and 400 V
class model groups. Note that General Specifications on page 7 in this chap-
ter apply to both voltage class groups. Footnotes for all specification tables fol-
low the table below.
Footnotes for the preceding table and the tables that follow:
Note 1 The protection method conforms to JEM 1030.
Note 2 The applicable motor refers to a standard 3-phase motor (4p). When using
other motors, care must be taken to prevent the rated motor current (50/
60 Hz) from exceeding the rated output current of the inverter.
Note 3 The output voltage decreases as the main supply voltage decreases (except
when using the AVR function). In any case, the output voltage cannot exceed
the input power supply voltage.
Note 4 To operate the motor beyond 50/60 Hz, consult the motor manufacturer for the
maximum allowable rotation speed.
Note 5 For achieving approved input voltage rating categories:
• 460 to 480 VAC - Over-voltage category 2
• 380 to 460 VAC - Over-voltage category 3
To meet the Over-voltage category 3, insert an EN or IEC standard compliant
isolation transformer that is earth grounded and star connected (for Low Volt-
age Directive).
Note 6 At the rated voltage when using a standard 3-phase, 4-pole motor.
Note 7 The braking torque via capacitive feedback is the average deceleration torque
at the shortest deceleration (stopping from 50/60 Hz as indicated). It is not
continuous regenerative braking torque. The average deceleration torque var-
ies with motor loss. This value decreases when operating beyond 50 Hz. If a
Item Single-phase 200 V class Specifications
MX2 inverters, 200 V models AB001 AB002 AB004F AB007 AB015 AB022
Applica-
ble motor
size *2
kW VT 0.2 0.4 0.55 1.1 2.2 3.0
CT0.10.20.40.751.52.2
HPVT1/41/23/41.53 4
CT1/81/41/21 2 3
Rated
capacity
(kVA)
200 V VT 0.4 0.6 1.2 2.0 3.3 4.1
CT0.20.51.01.72.73.8
240 V VT 0.4 0.7 1.4 2.4 3.9 4.9
CT0.30.61.22.03.34.5
Rated input voltage Single-phase: 200 V-15% to 240 V+10%, 50/60 Hz±5%
Rated output voltage *3 3-phase: 200 to 240 V (proportional to input voltage)
Rated output current
(A)
VT1.21.93.56.09.612.0
CT1.01.63.05.08.011.0
Starting torque *6 200% at 0.5 Hz
Braking Without resistor 100%: ≤50 Hz
50%: ≤60 Hz
70%: ≤50 Hz
50%: ≤60 Hz
20%: ≤50 Hz
20%: ≤60 Hz
With resistor 150% 100%
DC braking Variable operating frequency, time, and braking force
Weight kg1.01.01.11.41.81.8
lb2.22.22.43.14.04.0

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
