Omron MX2 User Manual

xx
UL
®
Cautions, Warnings and Instructions
5
Terminal symbols and Screw size
Inverter Model Screw Size Required
Torque (N-m)
Wire range
MX2-AB001,
MX2-AB002,
MX2-AB004
M4 1.0
AWG16 (1.3mm
2
)
MX2-AB007 M4 1.4
AWG12 (3.3mm
2
)
MX2-AB015,
MX2-AB022
M4 1.4
AWG10 (5.3mm
2
)
MX2-A2001,
MX2-A2002,
MX2-A2004,
MX2-A2007
M4 1.0
AWG16 (1.3mm
2
)
MX2-A2015 M4 1.4
AWG14 (2.1mm
2
)
MX2-A2022 M4 1.4
AWG12 (3.3mm
2
)
MX2-A2037 M4 1.4
AWG10 (5.3mm
2
)
MX2-A2055,
MX2-A2075
M5 3.0
AWG6 (13mm
2
)
MX2-A2110 M6 5.9 to 8.8
AWG4 (21mm
2
)
MX2-A2150 M8 5.9 to 8.8
AWG2 (34mm
2
)
MX2-A4004,
MX2-A4007,
MX2-A4015
M4 1.4
AWG16 (1.3mm
2
)
MX2-A4022,
MX2-A4030
M4 1.4
AWG14 (2.1mm
2
)
MX2-A4040 M4 1.4
AWG12 (3.3mm
2
)
MX2-A4055,
MX2-A4075
M5 3.0
AWG10 (5.3mm
2
)
MX2-A4110,
MX2-A4150
M6 5.9 to 8.8
AWG6 (13mm
2
)

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
