110
"B" Group: Fine Tuning Functions Section 3-6
3-6-10 Display related parameters
Function code display restriction: b037 – The function code display restriction
allows you to arbitrarily switch the display mode or the display content on the
integrated operator.
1. Function-specific display mode (b037=01)
If a specific function has not been selected, the monitor does not show the
parameters concerning the specific function. Following table lists the details of
display conditions.
2. User setting display mode (b037=02)
The monitor displays only the codes and items that are arbitrarily assigned to
user parameters (U001~U032), except codes d001, F001 and b037.
"B" Function Run
Mode
Edit
Defaults
Func.
Code
Name Description EU Units
b037 Function code display restric-
tion
Seven option codes:
00 Full display
01 Function-specific display
02 User setting (and b037)
03 Data comparison display
04 Basic display
05 Monitor display only
8 00
No. Displayed conditions Displayed func. codes when condition
fulfilled.
12
nd
motor C001...C007=08 F202, F203, A201 to A204, A220, A244,
A245, A261, A262, A281, A282, A292 to
A296, b212, b213, b221 to b223, C241,
H202 to H204, H206
2 EzSQ A017=01,02 d023 to d027, P100 to P131
3 Sensorless vector control A044=03 d009, d010, d012, b040 to b046, C054 to
C059, H001, H005, H020 to H024, H030
to H034, P033, P034, P036 to P040
4 Sensorless vector control for
2
nd
motor
C001...C007=08 AND
A244=03
d009, d010, d012, b040 to b046, C054 to
C059, H001, H205, H220 to H224, H230
to H234, P033, P034, P036 to P040
5 Free V/F control A044=02 OR
C001...C007=08 AND
A244=02
b100 to b113
6 Free setting of electronic-
thermal
b013=02 OR
C001...C007=08 AND
b213=02
b015 to b020
7 VC or VP1.7 control A044=00,01 A041 to A043,A046, A047
8 VC or VP1.7 control for
2
nd
motor
C001...C007=08 AND
A244=00,01
A241 to A243, A246, A247
9 DC breaking A051=01,02 OR
C001...C007=07
A052 to A059
10 PID A071=01,02 d004, A072 to A079, A156, A157, C044,
C052, C053
11 EzCOM C096=01,02 C098 to C100, P140 to P155
12 Curving accel/deceleration A097,A098=01...04 A131, A132, A150 to A153
13 Controlled deceleration b050=01,02,03 b051 to b054
14 Breaking b120=01 b121 to b127
15 Decel. overvolt. suppress b130=01,02 b131 to b134
16 Simple positioning P003=01 d008, P004, P011, P012, P015, P026,
P027, P060to P073, P075, P077, H050,
H051
