Omron MX2 User Manual

189
Using Intelligent Input Terminals Section 4-5
4-5-15 Brake Confirmation
This function is for brake performance. Please refer to chapter 3 for the
detailed description of the function.
4-5-16 LAD Cancellation
This function is for canceling the set ramp time and changes the output speed
immediately according to the set speed. (Please refer to chapter 3 for the
detailed description of the function.)
4-5-17 Pulse Counter Clear
This function is for clearing the accumulated pulse numbers in case of posi-
tioning. (Please refer to chapter 3 for the detailed description of the function.)
Option
Code
Terminal
Symbol
Function
Name
State Description
44 BOK Brake
confirmation
ON Brake confirmation signal is being
given
OFF Brake confirmation signal is not
given
Valid for inputs: C001~C007
Required settings: b120~b127, C021~ C022
Option
Code
Terminal
Symbol
Function
Name
State Description
46 LAC LAD cancel-
lation
ON Disabling the set ramp time and
inverter output immediately follows
the speed command.
OFF Accelerates and decelerates
according to the set ramp time
Valid for inputs: C001~C007
Required settings:
Option
Code
Terminal
Symbol
Function
Name
State Description
47 PCLR Pulse
counter
clear
ON Clears the accumulated pulse
numbers.
OFF Does not clear the pulse numbers.
Valid for inputs: C001~C007
Required settings:

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
