191
Using Intelligent Input Terminals Section 4-5
4-5-19 Force Terminal Mode
The purpose of this intelligent input is to allow a device to force the inverter to
allow control of the following two parameters via the control terminals:
•
A001 – Frequency source setting (01 = control terminals [FW] and [RV]
•
A002 – Run command source setting (01 = control terminals [O] or [OI]
Some applications will require one or both settings above to use a source
other than the terminals. You may prefer to normally use the inverter's keypad
and potentiometer, or to use the ModBus network for control, for example.
However, an external device can turn ON the [F-TM] input to force the inverter
to (temporarily) allow control (frequency source and Run command) via con-
trol terminals. When the [F-TM] input is OFF, then the inverter uses the regu-
lar sources specified by
A001 and A002 again.
4-5-20 Permission for torque command input
This function is to permit the torque command input. (Please refer to chapter 3
for the detailed description of the function.)
Option
Code
Terminal
Symbol
Function
Name
State Description
51 F-TM Force
Terminal
Mode
ON Forces A001=01
(frequency source setting = control
terminal), and A002=01 (Run com-
mand source setting = control ter-
minal)
OFF Inverter applies the user setting for
A001 and A002 normally
Valid for inputs: C001~C007
Required settings:
Notes:
• When changing the [F-TM] state during Run Mode (inverter is driving the motor),
the inverter will stop the motor before the new
[F-TM] state takes effect.
Option
Code
Terminal
Symbol
Function
Name
State Description
52 ATR Permission
for torque
command
input
ON Inverter is ready to accept the
torque command.
OFF Inverter is in a normal mode.
Valid for inputs: C001~C007
Required settings:
