Using Intelligent Output Terminals Section 4-6
4-6-33 2
nd
Motor Selection
This function allows you to switch the inverter setting to control two different
types of motors. To use this function, assign function "
08" to one of the input
terminal and make it on or off. When 2nd motor parameters are selected, out-
put signal SETM turns on.
4-6-34 STO (Safe Torque Off) Performance Monitor
This signal is specific for Safe Stop function.
No. Codes Description No. Codes Description
1 F202 Acceleration time (1) 22 A295 Acc1 to Acc2 frequency transition point
2 F203 Deceleration time (1) 23 A296 Dec1 to Dec2 frequency transition point
3 A201 Frequency source 24 C241 Overload warning level
4 A202 Run command source 25 H202 Motor data selection
5 A203 Base frequency 26 H203 Motor capacity
6 A204 Maximum frequency 27 H204 Motor poles
7 A220 Multi-speed frequency 0 28 H205 Motor speed response
8 A241 Torque boost select 29 H206 Motor stabilization constant
9 A242 Manual torque boost value 30 H220 Motor constant R1 (Standard motor)
10 A243 Manual torque boost freq. 31 H221 Motor constant R2 (Standard motor)
11 A244 V/f characteristic curve 32 H222 Motor constant L (Standard motor)
12 A245 V/f gain 33 H223 Motor constant I0 (Standard motor)
13 A246 Voltage comp. gain for automatic torque boost 34 H224 Motor constant J (Standard motor)
14 A247 Slip comp. gain for automatic torque boost 35 H230 Motor constant R1 (Auto tuned data)
15 A261 Frequency upper limit 36 H231 Motor constant R2 (Autotuned data)
16 A262 Frequency lower limit 37 H232 Motor constant L (Autotuned data)
17 A281 AVR function select 38 H233 Motor constant I0 (Autotuned data)
18 A282 AVR voltage select 39 H234 Motor constant J (Autotuned data)
19 A292 Acceleration time (2)
20 A293 Deceleration time (2)
21 A294 Select method to switch to Acc2/Dec2 profile
Option
Code
Terminal
Symbol
Function
Name
State Description
60 SETM
2
nd
motor
selection
ON
2
nd
motor parameter sets are
selected
OFF
1
st
motor parameter sets are
selected
Valid for inputs: 11, 12, AL0 - AL2
Required settings:
Option
Code
Terminal
Symbol
Function
Name
State Description
62 EDM STO (Safe
Torque Off)
Performan-
ce Monitor
(Output
terminal 11
only)
ON
OFF
