322
Parameter Settings for Keypad Entry Section C-2
C-2-6 Expansion Card Functions
"P" parameters will be appeared when the expansion option is connected.
H103 PM motor capacity kW dependent ✕
H104 PM motor poles setting kW dependent ✕
H105 PM motor rated current kW dependent ✕
H106 PM motor constant R kW dependent ✕
H107 PM motor constant Ld kW dependent ✕
H108 PM motor constant Lq kW dependent ✕
H109 PM motor constant Ke kW dependent ✕
H111 Auto constant R kW dependent ✕
H112 Auto constant Ld kW dependent ✕
H113 Auto constant Lq kW dependent ✕
H116 PM Speed Response 100 ✓
H117 PM Starting Current 55 ✕
H118 PM Starting Time 1.00 ✕
H119 PM Stabilization Constant 100 ✓
H121 PM Minimum Frequency 8 ✓
H122 PM No-Load Current 10.00 ✓
H123 PM Starting Method Select 00 ✕
H131 PM Initial Magnet Position
Estimation 0 V Wait Times
10 ✕
H132 PM Initial Magnet Position
Estimation Detect Wait Times
10 ✕
H133 PM Initial Magnet Position
Estimation Detect Times
30 ✕
H134 PM Initial Magnet Position
Estimation Voltage Gain
100 ✕
"P" Group Parameters Default Setting B031=10 User
Setting
Func.
Code
Name (EU)
P001 Operation mode on expansion card
1 error
00 ✓
P003 [EA] terminal selection 00 ✕
P004 Pulse train input mode for feedback 00 ✕
P011 Encoder pulse-per-revolution (PPR)
setting
512. ✕
P012 Simple positioning selection 00 ✕
P015 Creep speed 5.00 ✓
P026 Over-speed error detection level 115.0 ✓
P027 Speed deviation error detection level 10.0 ✓
P031 Accel/decel time input selection 00 ✕
P033 Torque command input selection 00 ✕
P034 Torque command setting 0. ✓
P036 Torque bias mode 00 ✕
P037 Torque bias value 0. ✓
P038 Torque bias polarity selection 00 ✕
P039 Speed limit for torque-controlled
operation (forward rotation)
0.00 ✓
P040 Speed limit for torque-controlled
operation (reverse rotation)
0.00 ✓
"H" Group Parameters Default Setting B031=10 User
Setting
Func.
Code
Name (EU)
