ModBus Data Listing Section B-4
Parameter group H
Register
No.
Function name Function
code
R/W Monitoring and setting items Data
resolution
1501h Auto-tuning Setting H001 R/W 0 (disabling auto-tuning), 1 (auto-tuning
without rotation), 2 (auto-tuning with
rotation)
–
1502h Motor data selection, 1st motor H002 R/W 0 (Standard motor data), 2 (auto-tuned
data)
–
1503h Motor capacity, 1st motor H003 R/W 00(0.1kW)- 15 (18.5kW) –
1504h Motor poles setting, 1st motor H004 R/W 0 (2 poles), 1 (4 poles), 2 (6 poles),
3 (8 poles), 4 (10 poles
–
1505h (Reserved) – – – –
1506h Motor speed constant, 1st motor H005 R/W 1 to 1000 1[%]
1507h Motor stabilization constant,
1st motor
H006 R/W 0 to 255 1
1508h to
1514h
(Reserved) – – – –
1516h Motor constant R1, 1st motor H020 R/W 1 to 65530 0.001 [O]
1517h (Reserved) – – – –
1518h Motor constant R2, 1st motor H021 R/W 1 to 65530 0.001 [O]
1519h (Reserved) – – – –
151Ah Motor constant L, 1st motor H022 R/W 1 to 65530 0.01 [mH]
151Bh (Reserved) – – – –
151Ch Motor constant Io H023 R/W 1 to 65530 0.01 [A]
151Dh Motor constant J H024 (high) R/W 1 to 9999000 0.001
151Eh H024 (low) R/W
151Hf to
1524h
(Reserved) – – – –
1525h Auto constant R1, 1st motor H030 R/W 1 to 65530 0.001 [O]
1526h (Reserved) – – Inaccessible –
1527h Auto constant R2, 1st motor H031 R/W 1 to 65530 0.001 [O]
1528h (Reserved) – – – –
1529h Auto constant L, 1st motor H032 R/W 1 to 65530 0.01 [mH]
152Ah (Reserved) - - Inaccessible -
152Bh Auto constant Io, 1st motor H033 R/W 1 to 65530 0.01 [A]
152Ch Auto constant J, 1st motor H034 (high) R/W 1 to 9999000 0.001
152Dh H034 (low) R/W
152Eh to
153Ch
(Reserved) – – – –
153Dh Slip compensation P gain for V/f
control with FB
H050 R/W 0 to 10000 0.1
153Eh Slip compensation P gain for V/f
control with FB
H051 R/W 0 to 10000 1
1571h PM motor code setting H102 00 (Hitachi standard data)
01 (auto-tuned data)
–
1572h PM motor capacity H103 0.1/0.2/0.4/0.55/0.75/1.1/1.5/2.2/3.0/
3.7/4.0/5.5/7.5/11.0/15.0/18.5
–
1573h PM motor poles setting H104 2(0)/4(1)/6(2)/8(3)/10(4)/12(5)/14(6)/
16(7)/18(8)/20(9)/22(10)/24(11)/26(12)/
28(13)/30(14)/32(15)/34(16)/36(17)/
38(18)/40(19)/42(20)/44(21)/46(22)/
48(34) pole
–
1574h PM motor rated current H105 Set a level between 20% and 100% for
the rated inverter current
0.01 [A]
1575h PM motor constant R H106 0.001 to 65.535 Ω 0.001 [Ω]
1576h PM motor constant Ld H107 0.01 to 655.35 mH 0.01 [mH]
1577h PM motor constant Lq H108 0.01 to 655.35 mH 0.01 [mH]
